25–40 CBM Modular Cold storageRoom with Huihuang EnergySaving Air Cooler

  • Modular
  • Efficient
  • Intelligent

Raxlyn 25–40 CBM modular cold storage room combines energy-saving air cooling, PIR insulation and intelligent temperature control. Designed for commercial chilled and frozen storage, it provides stable -25°C to +10°C operation with flexible dimensions, doors and refrigeration configurations.

  • Temperature -25°C to +10°C
  • Storage Volume 25–40 CBM
  • Energy-saving air cooler improves heat exchange and reduces refrigeration energy consumption.
  • B1 flame-retardant PIR panels minimize heat infiltration and cold-air leakage.
  • WiFi/4G intelligent control enables remote monitoring, alarms and energy tracking.
  • Modular construction allows fast installation, relocation and future cold room expansion.
  • Reply Within 24 h
  • OEM & Custom Branding
  • Long-Term Spare Parts
25–40 CBM Modular Cold storageRoom with Huihuang EnergySaving Air Cooler Get a Quote
Overview

Modular Cold Storage Room Overview

Raxlyn 25–40 CBM modular cold rooms combine efficient cooling, PIR insulation and intelligent controls for flexible commercial cold storage applications.

View Specifications
Containerized cold room being crane-lifted onto a concrete base at a distribution site
  • Energy-Saving Air Cooling

    Huihuang air cooler improves heat exchange and airflow distribution while reducing frosting and unnecessary energy consumption.

  • High-Performance PIR Insulation

    B1 flame-retardant PIR panels provide low thermal conductivity and tight connections for efficient cold retention.

  • Intelligent Temperature Control

    FD-900 control supports WiFi/4G monitoring, temperature alarms and intelligent defrost for stable cold room operation.

  • Flexible Modular Configuration

    Dimensions, panel thickness, doors, voltage and refrigeration units can be customized for different commercial applications.

Specifications

Technical Specifications

Reference configuration for the two standard sizes. Dimensions, refrigeration capacity and electrical supply are confirmed for each project in the quotation drawing.

Item Parameter
Product Name Cold Storage Room
Voltage 380V / 220V / Customizable
Refrigerant R507
Dimensions (L × W × H) 3 × 2 × 2.2 m / Customizable
Panel Thickness -18 to 0°C — 100 mm / -25 to 0°C — 120 mm / -35 to 0°C — 150 mm
Control Panel Raxlyn FD-900 (4G or Wi-Fi)
Glass Doors Customizable
Cold Room Wall Panel PIR Panel
Applications Fruits / Vegetables / Meat / Beer / Dairy Products / Bread / etc.
Certification CE / NSF
Brand Name Raxlyn
Place of Origin Anhui, China
Compressor Brand Internationally Recognized Brands
MOQ 1 Piece
Warranty 1 Year
Configurations

Configured Around
What You Store

Choose the temperature version first, then add the upgrades your site and product need. Every option is built and tested in the factory, not retrofitted on site.

  • 0 → +15 °C

    Chilled Storage

    Fruit, vegetables, flowers, dairy and beverages — humidity-friendly air distribution.

    01
  • −18 → −25 °C

    Frozen Storage

    Meat, seafood, ice cream and frozen food, with heated door frames and pressure relief.

    02
  • Down to −40 °C

    Blast Freezer

    High-capacity unit and airflow for fast pull-down of fresh product to core temperature.

    03
  • Chill + Freeze

    Dual-Zone Room

    An insulated partition splits a 40HQ into two rooms, each with its own refrigeration.

    04
Optional Upgrades

Add any of these to your quotation.

  • Solar PV & Battery Package
  • Remote Temperature Monitoring
  • Stainless Steel Interior
  • Meat Hanging Rails
  • Shelving & Racking
  • PVC Strip Curtain
  • Sliding Door
  • Loading Ramp
  • Standby Refrigeration Unit
  • Custom Colour & Logo
How We Deliver

From Inquiry to Cold Storage

  1. 01

    Requirement Review

    Product, target temperature, daily loading and site power supply.

  2. 02

    Design & Quotation

    Heat-load calculation, layout drawing and a configured quotation.

  3. 03

    Production & Testing

    Built in our factory and pull-down tested before it is released.

  4. 04

    Shipping & Documents

    Ships as a standard container with export and customs paperwork.

  5. 05

    Start-Up Support

    Remote commissioning guidance and long-term spare parts supply.

FAQ

Frequently Asked Questions

  • What is the temperature range of this modular cold room?

    The cold room operates from -25°C to +10°C, suitable for both chilled and frozen storage applications.

  • What is the storage capacity?

    Standard configurations provide approximately 25–40 CBM of storage volume, with dimensions customizable according to project requirements.

  • What insulation panels are available?

    B1 flame-retardant PIR panels are available in 100 mm, 120 mm and 150 mm thickness options.

  • Can the cold room be monitored remotely?

    Yes. The FD-900 controller supports optional WiFi or 4G connectivity for remote monitoring, temperature alarms and operating management.

  • Can the cold room configuration be customized?

    Yes. Dimensions, doors, panel thickness, voltage, refrigeration units and temperature settings can be customized for different projects.
