Cold Storage Engineering

Energy-Saving Inverter MonoblockRefrigeration Unit for Cold Rooms

  • Efficient
  • Integrated
  • Precise

Raxlyn energy-saving inverter monoblock refrigeration unit integrates cooling, air circulation and intelligent control in one compact system. With 30–85 Hz variable-frequency operation and ±0.5°C temperature control, it provides efficient refrigeration for chilled and frozen cold rooms.

  • Frequency Range 30–85 Hz
  • Temperature Accuracy ±0.5°C
  • Inverter technology automatically adjusts cooling output to reduce unnecessary energy consumption.
  • Integrated monoblock design simplifies installation and reduces equipment space requirements.
  • Precise ±0.5°C temperature control maintains stable conditions for temperature-sensitive products.
  • Wide-angle airflow improves circulation and temperature uniformity throughout the cold room.
  • Reply Within 24 h
  • OEM & Custom Branding
  • Long-Term Spare Parts
Energy-Saving Inverter MonoblockRefrigeration Unit for Cold Rooms Get a Quote
Overview

Inverter Monoblock Refrigeration Unit Overview

Raxlyn inverter monoblock units combine refrigeration, intelligent control and efficient airflow for reliable chilled and frozen cold room applications.

View Specifications
Containerized cold room being crane-lifted onto a concrete base at a distribution site
  • Energy-Saving Inverter Operation

    Variable-frequency operation from 30–85 Hz automatically adjusts refrigeration output according to changing cooling demands.

  • Integrated Monoblock Design

    Condenser, evaporator and control components are integrated into one compact unit for convenient wall-mounted installation.

  • Precise Temperature Control

    Intelligent controls maintain approximately ±0.5°C temperature accuracy for stable and reliable cold room operation.

  • Efficient Air Circulation

    Wide-angle airflow and inverter fans improve heat exchange efficiency and maintain uniform cold room temperatures.

Specifications

Technical Specifications

Reference configuration for the two standard sizes. Dimensions, refrigeration capacity and electrical supply are confirmed for each project in the quotation drawing.

Technical Parameter Available Specification
Recommended Cold Room Area* Approximately 20–50 m²
Overall Dimensions From 1170 × 660 × 830 mm to 1350 × 800 × 950 mm
Power Supply 220V / 380V
Evaporation Temperature Range -42°C to +5°C
Design Condensing Temperature 40°C
Applicable Ambient Temperature -10°C to +45°C
Refrigerant R22 / R404A or Customized Options
Maximum Operating Current Approximately 10–18 A
Operating Power Approximately 1700–3700 W
Pressure Control Electronic Pressure Sensors
Variable-Frequency Range 30–85 Hz
Condenser Fan Power Approximately 180–380 W
Condenser Fan Quantity 1
Evaporator Fan Power Approximately 180–380 W
Evaporator Fan Quantity 1
Recommended Condensing Area* Approximately 20–50 m²
Recommended Evaporator Area* Approximately 20–50 m²
Net Weight Approximately 92–160 kg
Installation Method Wall-Mounted Embedded Installation
Configurations

Configured Around
What You Store

Choose the temperature version first, then add the upgrades your site and product need. Every option is built and tested in the factory, not retrofitted on site.

  • 0 → +15 °C

    Chilled Storage

    Fruit, vegetables, flowers, dairy and beverages — humidity-friendly air distribution.

    01
  • −18 → −25 °C

    Frozen Storage

    Meat, seafood, ice cream and frozen food, with heated door frames and pressure relief.

    02
  • Down to −40 °C

    Blast Freezer

    High-capacity unit and airflow for fast pull-down of fresh product to core temperature.

    03
  • Chill + Freeze

    Dual-Zone Room

    An insulated partition splits a 40HQ into two rooms, each with its own refrigeration.

    04
Optional Upgrades

Add any of these to your quotation.

  • Solar PV & Battery Package
  • Remote Temperature Monitoring
  • Stainless Steel Interior
  • Meat Hanging Rails
  • Shelving & Racking
  • PVC Strip Curtain
  • Sliding Door
  • Loading Ramp
  • Standby Refrigeration Unit
  • Custom Colour & Logo
How We Deliver

From Inquiry to Cold Storage

  1. 01

    Requirement Review

    Product, target temperature, daily loading and site power supply.

  2. 02

    Design & Quotation

    Heat-load calculation, layout drawing and a configured quotation.

  3. 03

    Production & Testing

    Built in our factory and pull-down tested before it is released.

  4. 04

    Shipping & Documents

    Ships as a standard container with export and customs paperwork.

  5. 05

    Start-Up Support

    Remote commissioning guidance and long-term spare parts supply.

FAQ

Frequently Asked Questions

  • What cold rooms is this monoblock refrigeration unit suitable for?

    It is suitable for fresh food, chilled, frozen and other commercial temperature-controlled cold rooms.

  • What is the variable-frequency operating range?

    The inverter refrigeration system operates from 30 to 85 Hz and automatically adjusts output according to cooling demand.

  • What temperature range can the unit support?

    The unit supports an evaporation temperature range from -42°C to +5°C for different refrigeration applications.

  • Is a separate machine room required?

    Generally, no. The integrated wall-mounted monoblock design reduces installation space and eliminates separate machine rooms in many applications.

  • What power supply options are available?

    Both 220V and 380V configurations are available, with electrical specifications customizable according to project and destination requirements.

Start Your Project

Tell Us What You Store.
We'll Engineer the Cold.

Send your storage temperature, room size and location — our engineers reply with a configured solution and quotation within 24 hours.
