Cold Room Panels & Doors

PU Sandwich Cold Room Panels

  • 20FT
  • 40HQ
  • Chilled / Frozen

20FT & 40HQ plug-and-run cold storage, delivered assembled with an integrated refrigeration system.

  • Temperature −40 °C → +15 °C
  • Sizes 20FT · 40HQ
  • Delivered assembled — no construction work on site
  • Monoblock or split refrigeration, sized to your load
  • Solar-ready off-grid package for unstable power
  • Factory-tested and shipped with export documents
Request a Quote
  • Reply Within 24 h
  • OEM & Custom Branding
  • Long-Term Spare Parts
PU Sandwich Cold Room Panels Get a Quote
Overview

Cold Storage That Arrives
Ready to Run

A containerized cold room removes the slowest part of a cold-storage project: building on site. The insulated room, refrigeration unit and electrical system are assembled inside a steel ISO container and pull-down tested before it leaves the factory.

On arrival it only needs a level base and the specified power supply. Because the container keeps its corner castings, the room can be lifted, relocated or shipped again when your operation grows or moves.

View Specifications
Containerized cold room being crane-lifted onto a concrete base at a distribution site

  • Plug & Run Delivery

    Panels, refrigeration, wiring and lighting are installed and tested before shipment.

  • High-Density PU Insulation

    100–150 mm panels hold a stable room temperature, even in hot climates.

  • Right-Sized Refrigeration

    Monoblock or split units selected to your product, pull-down time and ambient temperature.

  • Digital Temperature Control

    Controller with alarms as standard; remote monitoring and data logging on request.

  • Relocatable Asset

    ISO corner castings for crane or forklift moves — the cold room moves with the business.

  • Solar-Ready Option

    PV array, charge controller and battery bank for sites without a stable grid supply.

Specifications

Technical Specifications

Reference configuration for the two standard sizes. Dimensions, refrigeration capacity and electrical supply are confirmed for each project in the quotation drawing.

Parameter 20FTStandard 40HQStandard
External size (L × W × H)6058 × 2438 × 2591 mm12192 × 2438 × 2896 mm
Internal size (L × W × H)5450 × 2290 × 2250 mm11580 × 2290 × 2550 mm
Usable volume≈ 28 m³≈ 67 m³
Temperature rangeChilled 0 → +15 °C · Frozen −18 → −25 °C · Blast freezing to −40 °C
InsulationPU sandwich panel, 100 mm (chilled) / 150 mm (frozen)
Refrigeration unit3–5 HP monoblock or split5–10 HP monoblock or split
RefrigerantR404A · R448A · R290 on request
Power supply380 V / 3 Ph / 50 Hz · 220 V / 60 Hz on request
DoorHinged, 800 × 1900 mmHinged 800 × 1900 mm or sliding 1200 × 2000 mm
FloorAluminium anti-slip chequer plate
Lighting & controlLED moisture-proof lights · digital controller with alarm
Configurations

Configured Around
What You Store

Choose the temperature version first, then add the upgrades your site and product need. Every option is built and tested in the factory, not retrofitted on site.

  • 0 → +15 °C

    Chilled Storage

    Fruit, vegetables, flowers, dairy and beverages — humidity-friendly air distribution.

    01
  • −18 → −25 °C

    Frozen Storage

    Meat, seafood, ice cream and frozen food, with heated door frames and pressure relief.

    02
  • Down to −40 °C

    Blast Freezer

    High-capacity unit and airflow for fast pull-down of fresh product to core temperature.

    03
  • Chill + Freeze

    Dual-Zone Room

    An insulated partition splits a 40HQ into two rooms, each with its own refrigeration.

    04
Optional Upgrades

Add any of these to your quotation.

  • Solar PV & Battery Package
  • Remote Temperature Monitoring
  • Stainless Steel Interior
  • Meat Hanging Rails
  • Shelving & Racking
  • PVC Strip Curtain
  • Sliding Door
  • Loading Ramp
  • Standby Refrigeration Unit
  • Custom Colour & Logo
Applications

Where It Works Best

From farm gate to supermarket back room — explore the storage solution built for your product.

How We Deliver

From Inquiry to Cold Storage

  1. 01

    Requirement Review

    Product, target temperature, daily loading and site power supply.

  2. 02

    Design & Quotation

    Heat-load calculation, layout drawing and a configured quotation.

  3. 03

    Production & Testing

    Built in our factory and pull-down tested before it is released.

  4. 04

    Shipping & Documents

    Ships as a standard container with export and customs paperwork.

  5. 05

    Start-Up Support

    Remote commissioning guidance and long-term spare parts supply.

FAQ

Frequently Asked Questions

  • What temperature can the containerized cold room maintain?

    The chilled and frozen versions cover −25 °C to +15 °C, and the blast-freezer version pulls down to −40 °C. The set point and refrigeration capacity are selected for the product you store, your daily loading volume and the ambient temperature on site.

  • What do I need on site to start it up?

    A level base — a concrete pad or steel sleepers — and the power supply stated on the drawing. The room arrives with panels, refrigeration, controller, lighting and wiring already installed, so there is no construction work: position it, connect power and start cooling.

  • What is the difference between the 20FT and 40HQ room?

    The 20FT room offers about 28 m³ of usable volume and suits single-zone chilling or freezing. The 40HQ more than doubles the volume, and the extra height allows taller racking, a second temperature zone or an internal loading aisle.

  • Is solar power included as standard?

    No — solar is an option. The standard unit runs on mains power, and we add the photovoltaic array, charge controller and battery bank when the site has no stable grid supply. Tell us the daily runtime you need and we size the off-grid package around it.

  • Can the room be customized for my brand and product?

    Yes. Panel thickness, internal height, door type and position, stainless interior, shelving, meat rails and dual-zone partitions are all built to order. For distributors we also supply custom exterior colours and your logo on OEM orders.

More Products

Related Products

View All Products
Start Your Project

Tell Us What You Store.
We'll Engineer the Cold.

Send your storage temperature, room size and location — our engineers reply with a configured solution and quotation within 24 hours.
